Montarbo B112 Active 12-inch Speaker 600W RMS/1200W Peak

B112 is a versatile, powerful, portable active speaker suitable for applications in medium venues.

The bass-reflex cabinet is equipped with a 12” woofer and a 1.35 ”compression driver boosted by a 1200 W Class D amp module.

B series’ advanced DSP featuring FIR filters allows a smooth audio performance as well as an impressive dimension/sound pressure level up to 129 dB.

B series speakers feature 3 input channels (Mic/line, Line, Bluetooth) with independent levels. Bluetooth devices can be easily connected thanks to the on-board “PAIR” button.

Moreover, 4 different on-board presets allows users to optimize the audio performance for the application in use.

A clean design integrates 3 handles and rigging points for fixed installation to the lightweight polypropylene cabinet which also allows horizontal stage monitor use, thanks to a 40° inclination of 2 sides of the box (a dedicated preset wedge EQ is selectable on board). The flange for pole fixing on the bottom of the box allows users to choose a 0° or a 7.5° inclination of the cabinet placed on a standard 35 mm tripod

Covers for transport and weather protection are available as accessories for every model in Montarbo B series.

System type
Two way bass reflex

MAX SPL
129 dB

Frequency Response (-10dB)
54Hz-20KHz

HF
1.35” (34mm) driver

LF
12” - 2.5” V.C (65mm)

Coverage (H x V)
90° H x 60° V

Crossover frequency
1.8 kHz

Amplifier class
D

RMS Power
600 W

Peak Power
1200 W

Cooling
Fan

Advanced Functions
FIR Filters

DSP
28/56 Bit

Bluetooth®
5.0 (stereo)

Connectors I/O
CH1: Combo CH2: XLR-F + jack 6,35mm (1/4”) AUX IN: mini-jack 3,5mm LINE OUT: XLR-M

Controls
Ch. levels, MAIN level, PRESET button, Channel sens. LINK/MIX selection

Cabinet
Polypropilene

Dimensions
365 x 625 x 345 mm (14.4” x 24.6” x 13.6”)

Weight
17.9 kg (39.46 lb)
