Montarbo B115 Active 15-inch Speaker 600W RMS/1200W Peak

The bass-reflex cabinet is equipped with a 15” woofer and a 1.35 ”compression driver boosted by a 1200 W Class D amp module. B series’ advanced DSP featuring FIR filters allows a smooth audio performance as well as an impressive dimension/sound pressure level up to 130 dB. B series speakers feature 3 input channels (Mic/line, Line, Bluetooth) with independent levels. Bluetooth devices can be easily connected thanks to the on-board “PAIR” button. Moreover, 4 different on-board presets allows users to optimize the audio performance for the application in use. A clean design integrates 3 handles and rigging points for fixed installation to the lightweight polypropylene cabinet which also allows horizontal stage monitor use, thanks to a 40° inclination of 2 sides of the box (a dedicated preset wedge EQ is selectable on board). The flange for pole fixing on the bottom of the box allows users to choose a 0° or a 7.5° inclination of the cabinet placed on a standard 35 mm tripod. Covers for transport and weather protection are available as accessories for every model in Montarbo B series.

System type
Two way bass reflex

MAX SPL
130 dB

Frequency Response (-10dB)
50Hz-20KHz

HF
1.35” (34mm) driver

LF
15” – 2.5” V.C (65mm)

Coverage (H x V)
90° H x 60° V

Crossover frequency
1.8 kHz

Amplifier class
D

RMS Power
600 W

Peak Power
1200 W

Cooling
Fan

Advanced Functions
FIR Filters

DSP
28/56 Bit

Bluetooth®
5.0 (stereo)

Connectors I/O
CH1: Combo CH2: XLR-F + jack 6,35mm (1/4”) AUX IN: mini-jack 3,5mm LINE OUT: XLR-M

Controls
Ch. levels, MAIN level, PRESET button, Channel sens. LINK/MIX selection

Cabinet
Polypropilene

Dimensions
430 x 725 x 405 mm (16.9” x 28.5” x 15.9”)

Weight
21.6 kg (47.62 lb)
