Montarbo R112 Active 12-inch wooden speaker 600W RMS/1200W Peak

The series is comprised of 4 wooden cabinets from 8 inches up to 15 inches, plus a single 15 and a single 18 active subwoofers. The full range cabinets allows for an impressive sound pressure as well as a clear, faithful reproduction of the vocal range. In facts, the sound processing takes advantage of FIR filters, resulting in a linear phase response and a very clear sound performance.

4 preset EQs, easily selectable on board, make prevision for maximum versatility in different applications, comprising wedge use. R series full-range speakers feature 2 Input channels with independent level controls, 1 mic/line combo input and an additional combo line in. A switch on the output channel allows users to select a link output signal or a mix between the 2 input channels.

The wooden enclosure of R series features a black elegant finish and a very clean design with aluminium handles which are flush with side panels, contributing to a very professional overall appearance.

Acoustical Data

Speaker Type
2-way Active bass reflex

Frequency Response [-10 dB]
51 Hz - 20 kHz

Max SPL
131 dB

HF
1.75" driver

LF
12" - 3" VC

Dispersion
90° H x 40° V

Crossover Frequency
1.5 kHz

Amplifier

Amp Class
D

RMS Power
600 W

Peak power
1200 W

Cooling
Passive Radiator

DSP

Advanced Functions
FIR Filters

DSP
28/56 Bit

AD/DA Converter
24 bit, 48 kHz

Controls
Channel level, MAIN level, PRESET, Channel 1 sensitivity, LINK/MIX output

Connectors
CH1: Combo, CH2: XLR-F + 6.35 mm jack (1/4”), LINE OUT: XLR-M

Enclosure

Dimensions
W x H x D
359 x 610 x 350 mm
[14.2” x 24” x 13.8”]

Weight
21 kg [46.3 lb]

Cabinet
Multilayer wood with polyurea finish
