RF 70-200mm F2.8L IS USM Z

70-200mm F2.8 telephoto zoom
Professional zoom for videos and stills

Optional RF 1.4x and RF 2x extenders
For extra flexibility and reach

Standard black or heat reflective white
To suit your shooting conditions

Short 70° zoom rotation
For quick and precise adjustments

Smooth action Iris Ring
With Auto Mode position iris lock

11-blade circular aperture
For creative control of bokeh and highlights

Image Stabilisation
5.5-stops Optical1, more when combined with IBIS4

Aspheric, Super UD and UD elements
For high image quality with maximum sharpness

Dual Nano USM motor
For smooth, fast and quiet autofocus

Custom buttons and Control ring
For easy customisation and control over camera settings

Optional Power Zoom Adapters
For smooth operation and zoom control

Optical Features / Specifications
Image Size
Full Frame
Angle of View (Horizontal, vertical, diagonal)
29° - 10°,
19° 30' - 7° ,
34° - 12°
Lens Construction (Elements/Groups)
18/15
Special Optics
3x Aspherical (inc 2x GMo and 1x replica), 2x Super UD, 1x UD (inc 1x UD Gmo Aspherical mentioned previously)
Special Features
Iris Ring
Number of Diaphragm Blades
11
Minimum Aperture
22
Closest Focusing Distance (m)
0.49m (at 70mm)
0.68m (at 200mm)
Maximum Magnification (x)
0.3x (at 200mm)
Control Ring
Yes
Image Stabilizer OIS1
EOS R8: 5.5 (Centre)2
Image Stabilizer IBIS x OIS3
EOS R1: 7.5 (Centre) / 7.0 (Corner)4
AF Actuator
Dual Nano USM
Coatings
ASC, Super Spectra
Fluorine
Front
Accessories
Lens Cap
E-82 II
Lens Hood
White model: ET-88C (WIII)
Black model: ET-88C (B)
Lens Case/Pouch
LZ1328
Rear End Cap
Lens Dust Cap RF
Extender Compatibility
Compatible with RF Extender only
Other Accessories
Lens Holder LH-E1,
Power Zoom Adapter PZ-E2 / PZ-E2B
Specifications with 1.4x Extender
Focal Length
98mm-280mm
Maximum Aperture
4
Maximum Magnification
0.42
AF Possible
Yes
Image Stabilizer
Yes
Specifications with 2x Extender
Focal Length
140mm-400mm
Maximum Aperture
5.6
Maximum Magnification
0.6
AF Possible
Yes
Image Stabilizer
Yes
Physical Specifications
Dust/Moisture Resistance5
Yes6
Exterior Coating
White model: Heat Shield
Black model: Standard
Filter Diameter (mm)
82
Max. Diameter x Length (mm)7
88.5 x 199
Weight (g)
White model: 1115 (excl. tripod mount)
Black model: 1110 (excl. tripod mount)
